Curve LED wall P2mm with Coating

Home » Products » Curve LED wall P2mm with Coating

Curve LED wall P2mm with Coating

Categories: China, INDOOR DISPLAY Tags: indoor led screen, led screen for rent, p4mm for indoor use, p4mm for rent, rental led display, 學校圖書館LED Wall, 醫院LED WALL工程

Description

Description

[vc_row][vc_column][vc_column_text]

Resolution

64(H)×64(V)

Pitch

2mm

Density

250,000 pixels/㎡

LED Arrangement

SMD2121

Driver Mode

Dynamic 1/32 Duty constant current

Size

128mm×128mm

Mask

Pure Black mask-high contrast screen

3.Electricity Parameter

Optical Ratings

Brightness

≥1000cd/㎡

View Angle

140 degree ( horizontal) 140degree(vertical)

View Distance

2m-20m

Gray Scale

8bits input, correction with 16bits

Display Color

16.7M

Brightness Adjustment

100 levels

Power Supply

Operation Power

AC100-240V 50-60HZ Switch-able

Maximum Power Consumption

950 W/m2

Average Power Consumption

480 W/m2

Control System

Correction Scale Level

16bits

Frame Update Frequency

60Hz

Screen Refresh Frequency

480-960Hz

Gamma Correction

-5.0—5.0

Support Input

Composite Video, S-Video, DVI, HDMI., SDI, HD_SDI

Control Distance

Ethernet cable 100m, optical fiber 5km

Support VGA Mode

800×600,1024×768,1280×1024,1600×1200

Color Temperature

5000-9300 adjustable

Brightness Correction

dot by dot, module by module, cabinet by cabinet

Reliability

Operating Temp.

-20-60 Celsius degree

Operating Humidity

10-95% RH

Operating Life

100,000 hours

MTBF

5000 hours

Continuous Working Time

≥48 hours

Protection Level

IP54

Out of Control Pixel Rate

0.01%
學校圖書館LED Wall
